KIT AA-1DLDRY
Free
Architecture / House
Manual
A 1/87 scale model of a ranch-style house. It features a 5/12 pitch hip roof. Exterior materials include vinyl or wood siding with a standing seam metal roof system. The structure includes 10 windows and 2 exterior doors. Architectural features include covered front porch, support posts and railings, window shutters, chimney with enclosed chase. The assembled model measures approximately 207 × 190 × 72 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 10
- Windows
- 10
- Exterior Doors
- 2
- Roof Type
- Hip
- Roof Pitch
- 5/12
- Roof Material
- Standing seam metal roof system
- Siding
- Vinyl or wood exterior siding
- Foundation
- Crawl space or basement foundation
Features
- Covered front porch
- chimney with enclosed chase
- double-panel door
- support posts and railings
- window shutters
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 206.84 | 189.31 | 71.86 |
| Perimeter #1 | 182.65 | 158.07 | 31.55 |
| Wall #2 | 106.93 | 31.55 | 5.26 |
| Wall #3 | 45.57 | 31.55 | 2.10 |
| Wall #4 | 73.62 | 31.55 | 2.10 |
| Wall #5 | 106.93 | 31.55 | 2.10 |
| Wall #6 | 57.84 | 31.55 | 2.10 |
| Wall #7 | 15.78 | 31.55 | 1.75 |
| Wall #8 | 64.86 | 31.55 | 5.26 |
| Wall #9 | 15.78 | 31.55 | 1.75 |
| Wall #10 | 54.34 | 31.55 | 2.10 |
| Wall #11 | 152.50 | 31.55 | 2.10 |
| Roof #12 | 196.32 | 178.79 | 38.59 |
| Base #13 | 206.84 | 189.31 | 1.75 |
| Railing #14 | 15.78 | 31.55 | 1.75 |
| Railing #15 | 15.78 | 31.55 | 1.75 |
