KIT AB-03P5RY
Free
Architecture / House
Manual
A 1/87 scale model of a ranch-style house. It features a 5/12 pitch gable roof. Exterior materials include brick veneer siding with a standing seam metal roof system. The structure includes 11 windows and a single exterior door. Architectural features include chimney with enclosed chase. The assembled model measures approximately 127 × 169 × 70 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 4
- Windows
- 11
- Exterior Doors
- 1
- Roof Type
- Gable
- Roof Pitch
- 5/12
- Roof Material
- Standing seam metal roof system
- Siding
- Brick veneer exterior siding
Features
- Chimney with enclosed chase
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 126.21 | 168.28 | 69.82 |
| Perimeter #1 | 110.43 | 159.51 | 31.55 |
| Wall #2 | 106.93 | 31.55 | 2.66 |
| Wall #3 | 156.01 | 31.55 | 2.63 |
| Wall #4 | 106.93 | 31.55 | 2.63 |
| Wall #5 | 156.01 | 31.55 | 2.63 |
| Roof #6 | 115.69 | 157.76 | 36.55 |
| Base #7 | 126.21 | 168.28 | 1.75 |
