KIT AE-0IR5RY
Free
Architecture / House
Manual
A 1/87 scale model of a two-story-style house. It features a 5/12 pitch gable roof. Exterior materials include engineered log siding with a standing seam metal roof system. The structure includes 16 windows and a single exterior door. Architectural features include covered front porch, support posts and railings, chimney with enclosed chase. The assembled model measures approximately 123 × 200 × 97 mm.
Specifications
- Type
- Two-story
- Scale
- 1/87
- Wall Panels
- 4
- Windows
- 16
- Exterior Doors
- 1
- Roof Type
- Gable
- Roof Pitch
- 5/12
- Roof Material
- Standing seam metal roof system
- Siding
- Engineered log exterior siding
Features
- Covered front porch
- chimney with enclosed chase
- glass-panel door
- support posts and railings
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 122.70 | 199.83 | 96.78 |
| Perimeter #1 | 105.17 | 164.77 | 52.59 |
| Wall #2 | 103.42 | 52.59 | 1.79 |
| Wall #3 | 163.02 | 52.59 | 1.75 |
| Wall #4 | 103.42 | 52.59 | 1.75 |
| Wall #5 | 163.02 | 52.59 | 1.75 |
| Roof #6 | 112.18 | 189.31 | 42.48 |
| Base #7 | 122.70 | 199.83 | 1.75 |
| Railing #8 | 15.78 | 52.59 | 1.75 |
| Railing #9 | 15.78 | 52.59 | 1.75 |
