KIT AF-0CR5RY
Free
Architecture / House
Manual
A 1/87 scale model of a two-story-style house. It features a 5/12 pitch gable roof. Exterior materials include brick veneer siding with a standing seam metal roof system. The structure includes 22 windows and a single exterior door. Architectural features include chimney with enclosed chase. The assembled model measures approximately 165 × 214 × 111 mm.
Specifications
- Type
- Two-story
- Scale
- 1/87
- Wall Panels
- 4
- Windows
- 22
- Exterior Doors
- 1
- Roof Type
- Gable
- Roof Pitch
- 5/12
- Roof Material
- Standing seam metal roof system
- Siding
- Brick veneer exterior siding
- Foundation
- Crawl space or basement foundation
Features
- Chimney with enclosed chase
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 164.77 | 213.85 | 110.86 |
| Perimeter #1 | 141.98 | 200.00 | 61.35 |
| Wall #2 | 138.48 | 61.35 | 11.60 |
| Wall #3 | 187.56 | 61.35 | 2.63 |
| Wall #4 | 138.48 | 61.35 | 2.63 |
| Wall #5 | 187.56 | 61.35 | 2.63 |
| Roof #6 | 154.25 | 203.33 | 47.80 |
| Base #7 | 164.77 | 213.85 | 1.75 |
