KIT AF-0TT5RY
Free
Architecture / House
Manual
A 1/87 scale model of a two-story-style house. It features a 5/12 pitch gable roof. Exterior materials include brick veneer siding with a standing seam metal roof system. The structure includes 15 windows and a single exterior door. Architectural features include covered front porch, support posts and railings, chimney with enclosed chase. The assembled model measures approximately 99 × 158 × 87 mm.
Specifications
- Type
- Two-story
- Scale
- 1/87
- Wall Panels
- 4
- Windows
- 15
- Exterior Doors
- 1
- Roof Type
- Gable
- Roof Pitch
- 5/12
- Roof Material
- Standing seam metal roof system
- Siding
- Brick veneer exterior siding
Features
- Covered front porch
- chimney with enclosed chase
- double-panel door
- glass-panel door
- support posts and railings
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 98.16 | 157.76 | 86.35 |
| Perimeter #1 | 75.37 | 117.44 | 52.59 |
| Wall #2 | 71.87 | 52.59 | 2.66 |
| Wall #3 | 113.94 | 52.59 | 2.63 |
| Wall #4 | 71.87 | 52.59 | 2.63 |
| Wall #5 | 113.94 | 52.59 | 2.63 |
| Roof #6 | 87.64 | 147.24 | 32.05 |
| Base #7 | 98.16 | 157.76 | 1.75 |
| Railing #8 | 15.78 | 52.59 | 1.75 |
| Railing #9 | 15.78 | 52.59 | 1.75 |
