KIT AG-1DS5RY
Free
Architecture / House
Manual
A 1/87 scale model of a two-story-style house. It features a 6/12 pitch gable roof. Exterior materials include vinyl or wood siding with a standing seam metal roof system. The structure includes 35 windows and 3 exterior doors. Architectural features include an attached garage, chimney with enclosed chase. The assembled model measures approximately 223 × 109 × 90 mm.
Specifications
- Type
- Two-story
- Scale
- 1/87
- Wall Panels
- 14
- Windows
- 35
- Exterior Doors
- 3
- Roof Type
- Gable
- Roof Pitch
- 6/12
- Roof Material
- Standing seam metal roof system
- Siding
- Vinyl or wood exterior siding
Features
- Attached garage
- chimney with enclosed chase
- double-panel door
- glass-panel door
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 222.61 | 108.68 | 89.83 |
| Perimeter #1 | 212.10 | 98.16 | 52.59 |
| Wall #2 | 53.29 | 52.59 | 1.75 |
| Wall #3 | 12.27 | 52.59 | 1.75 |
| Wall #4 | 66.96 | 52.59 | 1.79 |
| Wall #5 | 12.27 | 52.59 | 1.75 |
| Wall #6 | 53.29 | 52.59 | 1.75 |
| Wall #7 | 14.02 | 52.59 | 1.75 |
| Wall #8 | 36.81 | 52.59 | 1.79 |
| Wall #9 | 82.39 | 52.59 | 1.75 |
| Wall #10 | 36.81 | 52.59 | 1.75 |
| Wall #11 | 12.27 | 52.59 | 1.75 |
| Wall #12 | 22.79 | 52.59 | 1.79 |
| Wall #13 | 12.27 | 52.59 | 1.75 |
| Wall #14 | 150.75 | 52.59 | 1.75 |
| Wall #15 | 96.41 | 52.59 | 1.75 |
| Roof #16 | 212.10 | 98.16 | 35.52 |
| Base #17 | 222.61 | 108.68 | 1.75 |
