KIT AJ-27DSRY
Free
Architecture / House
Manual
A 1/87 scale model of a ranch-style house. It features a 6/12 pitch gable roof. Exterior materials include stone veneer siding with a standing seam metal roof system. The structure includes 11 windows and 2 exterior doors. Architectural features include covered front porch, support posts and railings, chimney with enclosed chase. The assembled model measures approximately 144 × 200 × 73 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 8
- Windows
- 11
- Exterior Doors
- 2
- Roof Type
- Gable
- Roof Pitch
- 6/12
- Roof Material
- Standing seam metal roof system
- Siding
- Stone veneer exterior siding
- Foundation
- Crawl space or basement foundation
Features
- Covered front porch
- chimney with enclosed chase
- double-panel door
- glass-panel door
- support posts and railings
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 143.74 | 199.83 | 72.30 |
| Perimeter #1 | 127.96 | 175.22 | 35.06 |
| Wall #2 | 89.40 | 35.06 | 5.26 |
| Wall #3 | 42.07 | 35.06 | 2.63 |
| Wall #4 | 17.53 | 35.06 | 1.75 |
| Wall #5 | 124.45 | 35.06 | 2.63 |
| Wall #6 | 124.45 | 35.06 | 5.26 |
| Wall #7 | 124.45 | 35.06 | 2.63 |
| Wall #8 | 17.53 | 35.06 | 1.75 |
| Wall #9 | 42.07 | 35.06 | 2.63 |
| Roof #10 | 133.22 | 189.31 | 35.52 |
| Base #11 | 143.74 | 199.83 | 1.75 |
| Railing #12 | 15.78 | 35.06 | 1.75 |
| Railing #13 | 15.78 | 35.06 | 1.75 |
