KIT AJ-T3DSRY
Free
Architecture / House
Manual
A 1/87 scale model of a ranch-style house. It features a 6/12 pitch gable roof. Exterior materials include stone veneer siding with a standing seam metal roof system. The structure includes 8 windows and a single exterior door. Architectural features include chimney with enclosed chase. The assembled model measures approximately 92 × 102 × 63 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 4
- Windows
- 8
- Exterior Doors
- 1
- Roof Type
- Gable
- Roof Pitch
- 6/12
- Roof Material
- Standing seam metal roof system
- Siding
- Stone veneer exterior siding
Features
- Chimney with enclosed chase
- double-panel door
- glass-panel door
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 91.15 | 101.67 | 62.95 |
| Perimeter #1 | 68.36 | 92.90 | 31.55 |
| Wall #2 | 64.86 | 31.55 | 2.66 |
| Wall #3 | 89.40 | 31.55 | 2.63 |
| Wall #4 | 64.86 | 31.55 | 2.63 |
| Wall #5 | 89.40 | 31.55 | 2.63 |
| Roof #6 | 80.63 | 91.15 | 29.68 |
| Base #7 | 91.15 | 101.67 | 1.75 |
